21
099623
26,4 44
KEY PART PART 90,000 150,000
NO. NUMBER DESCRIPTION QTY. QTY.
1 HA2203 Handles 2 —
HA2205 Handles — 2
2 M12345-33 Screw, #10-24 x 1 3/4" 8 8
3 M12342-3 Wheel Support Frame 1 —
M12831-3 Wheel Support Frame — 1
4 NTC-3C Hex Nut, #10-24 8 8
5 097896-01 Wheel 2 2
6 M28526 Cap Nut 2 2
7 M51015-01 Axle 1 —
M16801-2 Axle — 1
1
2
3
5
ILLUSTRATED
PARTS
BREAKDOWN
AND PARTS
LIST
WHEELS AND HANDLES FOR 26,4 and 44
kW (90,000 AND 150,000 Btu/Hr) MODELS
4
7
6
