5
Operating Instructions
Features of your
Ice Maker
1 Ice Maker Door with
Viewing Barrier.
2 Control Panel.
(see page 6 for details)
3 Adjustable Legs.
4 Evaporator Coils.
5 Water Box.
6 Ice Shovel.
7 Water Fill line.
(Located in internal reservoir,
beneath ice bucket.)
8 Drain Plug.
(Lower left rear of unit)
9 Ice Bucket.
8
9
6
5
4
1
2
3
Exterior
Accessories
7
Interior
