Inserting batteries
1. Remove the battery pack from the tool by squeez-
ing the two tabs on the battery pack together and
slide the battery pack out of the tool.
2. Remove battery pack cover
from the battery holder by
squeezing the two tabs marked
PRESS and remove the battery
cover from the battery holder.
3. Paying special attention to the orientation of the
batteries, insert four AA batteries into the battery
holder. Note both diagrams on the battery holder
showing correct battery direction.
4. Align notch in battery pack cover with arrow in
the battery holder and press together press
together. The two parts will only fit together when
the arrow and notch are aligned. The two parts
will join together with a click.
5. Insert the battery pack into the tool by aligning
the arrow in the pack with the arrow on the tool.
The two parts will only fit together when the two
arrows align. The two parts will join together with
a click.
RISK OF FIRE USE ONLY 1.5V
ALKALINE BATTERIES ONLY.
Do not install backwards,
charge or put in fire. Batteries
may explode or leak.
Page 10
Remember, your new Dremel Cordless Rotary Tool
is the finest power tool of its kind. But its perfor-
mance is only as good as the accessories with
which it is used. We recommend only Dremel accessories be used. Use of any other accessories
may create a hazard. We hope you’ll enjoy many
years of trouble free pleasure from your Dremel
Cordless Rotary Tool.
PRESS
WARNING !
WARNING !
BATTERY PACK
RELEASE TAB
BATTERY PACK COVER
BATTERY HOLDER BATTERY PACK COVER
RELEASE TABS
BATTERY
PACK
COVER
BATTERY
HOLDER
ALIGNMENT
MARKS
