14
R/Pr G/Y B/Pb H/HV V
PC control
DVI
INPUT 1
R/C jack
USB
reset
(mono)
(mono)
(mono)
(mono)
audio
PC control
S-video video/Y C
INPUT 2
INPUT 3
audio
audio
serial port IN serial port OUT audio OUT
R L
R
R
R
L
L
L
CONNECTING TO COMPUTER
IBM-compatible computers or Macintosh computers (VGA / SVGA / XGA / SXGA/UXGA)
VGA Cable
Monitor Output
Desktop type Laptop type
Control Cable
for Serial Port
Audio Cable
(stereo) ✽
Serial port PS/2 port Audio Output
Audio Input
AUDIO OUT
Use one of these Control
Cables corresponding
with terminal of your
computer.
MAC/VGA
Adapter
Set slide switches
following chart
below.
ADB port
Cables used for connection ( ✽ = Cables are not supplied with this projector.)
• VGA Cable (HDB 15 pin)
• Control Cable for PS/2 port, Serial port, or ADB port
• MAC/VGA Adapter, DVI/VGA Adapter
• DVI Cable
• BNC Cable (BNC x 5)
✽
• Audio Cables (RCA x 2) ✽
Control Cable
for PS/2 Port
Control Cable
for ADB Port
Audio Cable
(stereo) ✽
NOTE :
When connecting cable, power cords of both a
projector and external equipment should be
disconnected from AC outlet. Turn a projector
and peripheral equipment on before computer is
switched on.
Terminals of
a Projector
Audio Amplifier
Audio Speaker
(stereo)
External Audio Equipment
Monitor Output
DVI Cable
BNC Cable ✽
Monitor Output
Set switches as shown in table below depending on
RESOLUTION MODE that you want to use before
your turn on a projector and computer
13"MODE (640 x 480)
16"MODE (832 x 624)
19"MODE (1024 x768)
21"MODE (1152 x 870)
ON
OFF
OFF OFF OFF OFF
OFF OFF OFF
OFF OFF OFF
ON
ON
ON ON ON
OFF
OFF OFF
ON ON
ON
ON
1 2 3 4 5 6 MODE
SWITCHES
Switches of
MAC/VGA Adapter
ON
1
DIP
ON
OFF
2 3 4 5 6
MAC/VGA ADAPTER
CONNECTING PROJECTOR
DVI/VGA
Adapter
E
Terminal Terminal Terminal
