Page 15
15
1. Place battery in rack with terminals facing
towards generator head.
2. Place battery bracket (A) over battery as shown
(opposite battery terminals).
3. Place "L" bolt (B) through top and bottom brackets
and secure with wing nut (C).
Positive
( + )
N e g a t i v e
( - )
INSTALLATION OF BATTERY
• Recommended Battery for Electric Start •
Use standard 12 volt 45 amp hour lawn mower battery
