Chapter 2 installation instructions – Foxconn CK804K8MA-KS User Manual
Page 23
15
Chapter 2 Installation Instructions
CK804K8MA Series User Manual
Center
Front Left
Front Right
Rear Left
Rear Right
Subwoofer
Blue
Green
Red
Line-out
Line-in
Microphone
When using a 6-channel sound source, connect the front speaker to the green
audio output; connect the surround sound speaker to the blue audio input; connect
the center speaker/subwoofer to the red Microphone input, as shown in the follow-
ing figure:
CK804K8MA-manual-V1.0-111704.p65
2004-11-19, 14:51
15
