Attach the power LED, IDE LED, reset switch and power switch connectors to the
corresponding pins.
4. Front Panel Connector: FP1
Plug the CPU cooling fan cable into the 3-pin CPU FAN power supply on the mainboard.
Connect the case cooling fan connector to FAN1.
5. CPU FAN & FAN1
CPU_FAN
GND
+12V
SENSE
1
FAN1
FP1
1 +
-
NC
HDLED
RESET
PLED
PSWITCH
+
-
SENSE +12V GND
1
