® Dayton Natural Gas
Construction Heater
Manufactured for Dayton Electric Mfg. Co.
Niles, Illinois 60714 U.S.A. 103888-01
Rev. E
05/02
Version B - For Reduction G016.J
®
Reference
Number
Description Part No. Quantity
Use only original repair parts. This heater must use design-specific parts. Do not substitute or use
generic parts. Improper repair parts could cause serious or fatal injuries. This will also protect your
warranty coverage for parts replaced under warranty.
41 * #10-32 x 1/4" Screw M12461-25 2
42 Union 1/2 NPT to 1/2 NPT Fitting 103407-01 1
43 Clip Nut M11271-8 8
44 High Temperature Wire Assembly 101480-10 1
45 High Temperature Wire Assembly 101480-11 1
46 Plug 1/8 NPTF Hex 098276-01 1
47 * Hex TPG “F” 6-32 s 1/4" Screw M10908-1 2
48 Built-in Thermostat 097657-03 1
49 Thermostat Knob 104905-01 1
50 Baffle Screw 103400-02 1
51 DSI Control No. 2003-19 M51605-02 1
52 DSI Control No. 2003-45 M51605-05 1
53 DSI Wire Harness (DSI Control 2003-45 only) 110267-01 1
∆ Wiring Decal (DSI Control 2003-45 only) 103402-03 1
∆ Wiring Decal (DSI Control 2003-19 only) 103402-01 1
∆ Wire Assembly (2003-45 only) M16841-20 1
∆ Service Center List M50985-01 1
∆ Tradename Decal 099153-08 2
∆ General Information Decal 103886-02 1
∆ Thermostat Decal 103021-01 1
∆ Warning Decal 099504-01 2
∆ NG Warning Decal 103889-01 1
( ∆ ) Not shown.
(*) Standard hardware item, available locally.
