11
Installation –
continued
Table 1
Function
e. g. First low-level alarm
e. g. Feed pump ON
e. g. High level alarm
e. g. Feed pump OFF
Function Electrode rod
3
4
2
1
Length [mm]
Attention
■ The seating surfaces of the threads or flange provided on the vessel or
boiler standpipe must be accurately machined. Fig. 5
■ Do not bend electrode rod when mounting.
■ Do not lag electrode body.
Note
■ For the approval of the boiler standpipe with connecting flange the
relevant local and national regulations must be considered.
■ See four examples of installation on page 17.
Tools
■ Open-end spanner 41 mm A. F.
■ Bolt cutter
■ Hacksaw
■ Flat file, medium cut
