Troubleshooting
- continued -
Diagnosis
Display 1 and activity Display 2 Fault Remedy
LED alarm and
diagnosis LED
illuminated. Press and hold
down key 1.
Diagnosis
LED
flashing.
Malfunction in level elec-
trode , malfunction in level
switch, faulty wiring,
faulty measuring voltage.
- check wiring,
- measure electrode voltages,
- clean and, if necessary exchange
level electrode,
- exchange level switch.
Diagnosis
LED
flashing.
Malfunction in level elec-
trode , malfunction in level
switch, faulty wiring.
Diagnosis
LED 3
flashing.
Interference voltage causing
malfunction, boiler earth
without PE
Provide screen and earthing, connect
boiler with PE.
LED alarm and
and Diagnosis LED 3
illuminated. Press and hold
down key 1 or 2.
Diagnosis
LED
flashing.
Malfunction in processor,
stand-by fault.
Observe operating instructions for the
logic unit SRL.
Replace level switch.
Diagnosis
LED
flashing.
Internal voltage fault.
Replace level switch.
Diagnosis
LED 3
flashing.
Malfunction in relay.
Once the fault is eliminated, the level switch returns to normal operation.
After elimination of the fault switch off the mains voltage and switch it on again after approx. 5 sec.
Fault indication
Status Diagnosis Function Next activity
Faulty evaluation of level
electrode , channel
Diagnosis LED and
LED alarm illuminated.
Output contacts are opened
instantaneously.
Signal output closes
instantaneously.
next:
Press key 1.
Malfunction in level switch
detected.
Diagnosis LED 3 and
LED alarm and
illuminated.
Output contacts are opened
instantaneously.
Signal outputs and are closed
instantaneously.
next:
Press key 1 or
key 2.
Indication, diagnosis and remedy
- continued -
If faults occur that are not listed above or cannot be corrected, please contact our service centre or
authorized agency in your country.
