COMMON PARTS RELATED TO ALL ACTUATORS
NO. ITEM MATERIAL P/N QTY
1 Painted Cover Cast Aluminum 106100 1
2 5/16-24UNF HHCS/Shank Stainless Steel 103233 8
3 5/16 Type A Washer Stainless Steel 103715 8
4 1/2” Sleeve Bearing Sintered Bronze 105590 1
5 Molded Oil Seal Nitrile 105585 1
6 Manual Override Hub Black 141 Lexan 105567 1
7 7/16 I.D. Klipring Stainless Steel 106174 1
8 Handwheel (Optional) Black Plastic 105974 1
9 Manual Override Shaft Steel/Plated 105591 1
10 Brake Trip Washer Aluminum 107065 1
11 Manual Override Coupler Steel/Plated 106129 1
Manual Override Spring Spring Steel 105593 1
1/16 Dia. Roll Pin Spring Steel 103621 1
12 O-Ring, Base N674-70 Nitrile 105584 1
13 CE1/CE2 Machined Base Cast Aluminum 106098 1
CE4/CE7 Machined Base Cast Aluminum 106099 1
CE5 Machined Base Cast Aluminum 107503 1
14 3/8” Needle Bearing Steel/Plated 105582 1
15 3/8” Sleeve Bearing Sintered Bronze 105581 4
16 O-Ring, Output Shaft N674-70 Nitrile 105583 1
17 1-1/2” Sleeve Bearing Sintered Bronze 409944 1
18 CE1/CE2 Motor Plate Cast Aluminum 106080 1
CE4/CE7 Motor Plate Cast Aluminum 106081 1
CE5 Motor Plate Cast Aluminum 107504 1
19 5/8” Sleeve Bearing Sintered Bronze 105694 1
20 8-32UNC Ground Screw Steel/Plated 103627 1
21 #8 Cup Washer Brass 105626 1
22 8-32UNCx5/8” Hex Screw Steel/Plated 105577 5
23 8-32UNCx5/8” Phillips Hd. Steel/Plated 105576 1
24 Actuator Bracket Steel/Plated 108099 1
27 M.O. Cut-off Switch Plastic/Steel 105769 1
28 Switch Insulator Gasket Vulcanized Fiber 103675 5
29 4-40UNCx5/8” Phillips Hd.S Steel/Plated 106146 2
30 4-40UNCx1-1/4” Phillips Hd. Steel/Plated 100159 2
31 3/16” Higher Spacer Nylon 105679 2
32 15 Amp Switch Plastic/Steel 107765 2
33 3/16” Pop-in Bearing Plastic 105851 1
34 Camshaft Steel/Plated 107005 1
35 Large 4-Deg. Spline Shaft Plastic 103571 1
1/16” Dia. Roll Pin Spring Steel 103621 1
36 Small 4-Deg. Spline Shaft Plastic 103572 1
1/16” Dia. Roll Pin Spring Steel 103621 1
37 Switch Spring Spring Steel 103714 1
38 Hi-Ramp Cam Plastic 107322 2
39 CE2/CE4 Output Shaft Ass’y Steel 106096 1
CE5 Ouput Shaft Ass’y Steel 107700 1
CE1/CE7 Output Shaft Ass’y Steel 106097 1
40 CE1/2/5/& 7 Offset Shaft Steel 86L20 104864 1
1/8x1/8x1.19” Long Key Steel 105589 1
41 CE1 Offset Pinion Steel -Heat Treated 104893 1
CE2 Offset Pinion Steel -Heat Treated 104887 1
CE4 Offset Pinion Steel -Heat Treated 104889 1
CE7 Offset Pinion Steel -Heat Treated 104891 1
CE5 Offset Pinion Steel -Heat Treated 107169 1
42 CE1/CE7 Offset Gear Steel -Heat Treated 104890 1
CE2 Offset Gear Steel -Heat Treated 104885 1
CE4 Offset Gear Steel -Heat Treated 104884 1
CE5 Offset Gear Steel -Heat Treated 107168 1
43 1.00 O.D.x 0.031 Spacer Steel 105587 1
44 9/16” I.D. Snap Ring Spring Steel 100678 2
58 Nameplate Stainless Steel 105578 1
Ty-Rap Cable Tie Plastic 101066 2
3/32” Dia. Drive Pins Stainless Steel 105454 2
Cam Adjustment Sticker Mylar 105757 1
Manual Override Sticker Mylar 105756 1
Accord Logo Sticker Mylar 105862 2
Position Indication Sticker Mylar 106187 1
3/4” NPT Conduit Plug Plastic 103685 1
Open/Close Stickers Mylar 106186 1
59 Press Fit Washer Steel 107178 1
60 Plug Steel/Plated 107126 2
ADDITIONAL PARTS SPECIFIC TO 115 VAC
ACTUATORS CE2, CE4, CE7, CE1, CE5
NO. ITEM MATERIAL P/N QTY.
49 115 VAC PSC Motor Int. Steel/Copper 105675 1
16 Fin Impeller Fan Plastic 105703 1
10-32UNCx3/16” SHCS Steel/Plated 105599 2
54 Capacitor Plastic Encapsulated 106619 1
55 Wire Tie Plastic 106243 2
56 Quick Connect Plastic/Steel 106761 4
25 6 Position Terminal Strip Plastic/Steel 103997 1
2 Screw Marker Strip Plastic 103996 1
26 3-48UNCx1/2” Pan Head Steel/Plated 104837 2
115 VAC Wire Harness Copper/Plastic 106111 1
115 VAC Schematic Sticker Gloss Paper 815169 1
ADDITIONAL PARTS SPECIFIC TO 115 VAC WITH ESP SERVO
POSITIONER ACTUATORS CE2ATA, CE4ATA, CE7ATA, CE1ATA, CE5ATA
NO. ITEM MATERIAL P/N QTY.
49 115 VAC PSC Motor Ext. Steel/Copper 105676 1
Fan Hub Pressed Metal 107939 1
Fan Plastic 107940 1
Compression Spring Steel 108431 1
Brake Hinge Ass’y Steel/Plastic 108600 1
52 Brake Solenoid Coil 108022 1
Switch Spring Steel 103714 1
Wave Spring Steel 108198 1
10-32UNF Set Screw Stainless Steel 103486 1
.75x.459x.042 Washer Brass 108361 1
Klip Ring Stainless Steel 106174 1
6-32 x 1/2 Phil. Screw Steel 106061 1
.350 x .118 Lg. Spacer Bronze 108296 2
6-32 Hex. Nut Nylon/Steel 105864 1
10-32UNF SHCS Steel 105599 2
#6 Type A Plain Washer Steel 100986 3
Brake Shim Steel 108199 1
8-32 x 5/8 Phil. Screw Steel 105576 3
55 Wire Tie Plastic 106243 2
56 Quick Connect Plastic/Steel 106761 4
54 Capacitor Plastic Encapsulated 106618 1
#6 x 0.19lg. Spacer Aluminum 100839 1
6-32UNCx3/8” Phillips Hd. Steel/Plated 100881 1
1/4 Turn Standoff Plastic 105168 2
ESP3 Servo Positoner Fiberglass 105005 1
Potentiometer Plastic 106195 1
85- Tooth Gear Aluminum 107312 1
85- Tooth Gear Aluminum 105853 1
26 115 VAC ESP3 Wire Harness Copper/Plastic 106194 1
ESP3 Schematic Sticker Glass Paper 815224 1
ADDITIONAL PARTS SPECIFIC TO 12 VDC ACTUATORS
CE2B, CE4B, CE7B, CE1B, CE5B
NO. ITEM MATERIAL P/N QTY
49 12 VDC Gearmotor Steel/Copper 106088 1
Motor Bracket Spacer Aluminum 106193 2
25 6 Piston Terminal Strip Plastic/Steel 103997 1
2 Screw Marker Strip Plastic 103996 1
26 3-48UNCx1/2” Pan Head Steel/Plated 104837 2
12 VDC Wiring Harness Copper/Plastic 106196 1
12 VDC Schematic Sticker Gloss Paper 815176 1
ADDITIONAL PARTS SPECIFIC TO 24 VDC ACTUATORS
CE2C, CE4C, CE7C, CE1C, CE5C
NO. ITEM MATERIAL P/N QTY
49 24 VDC Gearmotor Steel/Copper 106088 1
Motor Bracket Spacer Aluminum 106193 2
25 6 Position Terminal Strip Plastic/Steel 103997 1
2 Screw Marker Strip Plastic 103996 1
26 3-48UNCx1/2” Pan Head Steel/Plated 104837 2
24 VDC Wiring Harness Copper/Plastic 106197 1
24 VDC Schematic Sticker Gloss Paper 815176 1
