Page 3
WCAIM2022
Supplement 3: ACCESS I and M DeviceNet EDS File
3
Flow Control
Worcester Controls
Param11 =
0,
$ parameter value slot
6, “20 09 24 02 30 04”,
$ link size and path
0x32, $
descriptor
4, 1,
$ data type, 1 byte(s)
“Status Instance 2”,
$ parameter name
“”,
$ units string
“Discrete Output Point\n\n”,
0,1,0,
1,1,1,0,0,0,0,0,0;
Param12 =
0,
$ parameter value slot
6, “20 09 24 02 30 05”,
$ link size and path
0x03, $
descriptor
4, 1,
$ data type, 1 byte(s)
“Fault Action Instance 2”,
$ parameter name
“”,
$ units string
“Discrete Output Point\n\n”,
0,1,0,
1,1,1,0,0,0,0,0,0;
Param13 =
0,
$ parameter value slot
6, “20 09 24 02 30 06”,
$ link size and path
0x03, $
descriptor
4, 1,
$ data type, 1 byte(s)
“Fault Value Instance 2”,
$ parameter name
“”,
$ units string
“Discrete Output Point\n\n”,
0,1,0,
1,1,1,0,0,0,0,0,0;
Param14 =
0,
$ parameter value slot
6, “20 09 24 02 30 07”,
$ link size and path
0x03, $
descriptor
4, 1,
$ data type, 1 byte(s)
“Idle Action Instance 2”,
$ parameter name
“”,
$ units string
“Discrete Output Point\n\n”,
0,1,0,
1,1,1,0,0,0,0,0,0;
Param15 =
0,
$ parameter value slot
6, “20 09 24 02 30 08”,
$ link size and path
0x03, $
descriptor
4, 1,
$ data type, 1 byte(s)
“Idle Value Instance 2”,
$ parameter name
“”,
$ units string
“Discrete Output Point\n\n”,
0,1,0,
1,1,1,0,0,0,0,0,0;
Param16 =
0,
$ parameter value slot
6, “20 40 24 01 30 01”,
$ link size and path
0x01, $
descriptor
9, 4,
$ data type, 4 byte(s)
“Maintenance Counter Instance 1”, $ parameter name
“”,
$ units string
“”,
0,4294967295,0,
1,1,1,0,0,0,0,0,0;
Param17 =
0,
$ parameter value slot
6, “20 40 24 01 30 02”,
$ link size and path
0x10, $
descriptor
9, 4,
$ data type, 4 byte(s)
“Cumulative Counter Instance 1”, $ parameter name
“”,
$ units string
“”,
0,4294967295,0,
1,1,1,0,0,0,0,0,0;
Param18 =
0,
$ parameter value slot
6, “20 40 24 01 30 03”,
$ link size and path
0x10, $
descriptor
8, 1,
$ data type, 1 byte(s)
“Open Timer Instance 1”,
$ parameter name
“Secs”,
$ units string
“”,
0,255,0,
1,1,1,0,0,0,0,0,0;
