Supplement 3: ACCESS I and M DeviceNet EDS File
WCAIM2022
Flow Control
Worcester Controls
Param3 =
0,
$ parameter value slot
6, “20 08 24 03 30 03”,
$ link size and path
0x32, $
descriptor
4, 1,
$ data type, 1 byte(s)
“Input State Instance 3”,
$ parameter name
“”,
$ units string
“Discrete Input Point\n\n”,
0,1,0,
1,1,1,0,0,0,0,0,0;
Param4 =
0,
$ parameter value slot
6, “20 09 24 01 30 03”,
$ link size and path
0x03, $
descriptor
4, 1,
$ data type, 1 byte(s)
“State Instance 1”,
$ parameter name
“”,
$ units string
“Discrete Output Point\n\n”,
0,1,0,
1,1,1,0,0,0,0,0,0;
Param5 =
0,
$ parameter value slot
6, “20 09 24 01 30 04”,
$ link size and path
0x32, $
descriptor
4, 1,
$ data type, 1 byte(s)
“Status Instance 1”,
$ parameter name
“”,
$ units string
“Discrete Output Point\n\n”,
0,1,0,
1,1,1,0,0,0,0,0,0;
Param6 =
0,
$ parameter value slot
6, “20 09 24 01 30 05”,
$ link size and path
0x03, $
descriptor
4, 1,
$ data type, 1 byte(s)
“Fault Action Instance 1”,
$ parameter name
“”,
$ units string
“Discrete Output Point\n\n”,
0,1,0,
1,1,1,0,0,0,0,0,0;
Param7 =
0,
$ parameter value slot
6, “20 09 24 01 30 06”,
$ link size and path
0x03, $
descriptor
4, 1,
$ data type, 1 byte(s)
“Fault Value Instance 1”,
$ parameter name
“”,
$ units string
“Discrete Output Point\n\n”,
0,1,0,
1,1,1,0,0,0,0,0,0;
Param8 =
0,
$ parameter value slot
6, “20 09 24 01 30 07”,
$ link size and path
0x03, $
descriptor
4, 1,
$ data type, 1 byte(s)
“Idle Action Instance 1”,
$ parameter name
“”,
$ units string
“Discrete Output Point\n\n”,
0,1,0,
1,1,1,0,0,0,0,0,0;
Param9 =
0,
$ parameter value slot
6, “20 09 24 01 30 08”,
$ link size and path
0x03, $
descriptor
4, 1,
$ data type, 1 byte(s)
“Idle Value Instance 1”,
$ parameter name
“”,
$ units string
“Discrete Output Point\n\n”,
0,1,0,
1,1,1,0,0,0,0,0,0;
Param10 =
0,
$ parameter value slot
6, “20 09 24 02 30 03”,
$ link size and path
0x03, $
descriptor
4, 1,
$ data type, 1 byte(s)
“State Instance 2”,
$ parameter name
“”,
$ units string
“Discrete Output Point\n\n”,
0,1,0,
1,1,1,0,0,0,0,0,0;
