9. Dress and cable tie all wiring as shown on Figure 1.
10. Apply power to proper actuator terminals to set cams:
• to terminals 1 and 3 for counterclockwise operation
• to terminals 1 and 4 for clockwise operation
To set cams actuate valve to “Open” position. If valve does not
fully open, or turns past open position, unfasten cam by loosen-
ing set screws. Actuate valve to correct position. Adjust cam so
that it just throws microswitch in this position.
Tighten set screws and recheck indexing. Repeat this procedure
for “Closed” position.
11. Connect remaining input wiring to terminal strip.
NOTE: All wiring to terminal strip should be inserted only to
midpoint of terminal strip.
12. When electrical installation is complete, it is advisable to check
the indexing of the actuator before replacing the cover.
Figure 1—25/30 75 Motor Module Kits for either 120 VAC or 240 VAC Actuators
1. Motor Support Plate
2. Motor
3. Pinion Gear
4. Sensing Shaft
5. Fan
6. Set Screw
7. Socket Head Cap Screw
8. Lockwasher
9. Cable Tie
10. Cams
11. Retaining ring
12. Capacitor (Round or Square Type)
13. Capacitor Tie
14. Capacitor Bracket *
15. Screw-Capacitor Bracket *
* Not used with round type capacitor
with threaded lug.
BLACK FROM
P.C.B.
RED FROM
P.C.B.
WHITE FROM MOTOR
BLUE TO
CAPACITOR
CAPACITOR
GRAY TO
WIRING FOR A75 240 VAC AF17 OR DFP17
POSITIONER OR DFC17 CONTROLLER OR DRC17
.96"
REMOTE CONTROLLER OR T75 240 VAC INTERFACE OPTIONS
G
G
1
2
4
3
7
8
6
5
9
10
11
12
1
BLUE
YELLOW
WHITE
RED
WHITE
GRAY
BROWN
BLUE
YELLOW
BLACK
SW2
SW
1
13
12
9
BLUE
BLK.
5
WHITE
2
1
3
4
RED
SW2
GRAY
6
7
9
8
12
11
10
SW
1
BLACK
RED
6
3
7 & 8
2
5
GRAY
11
4
10
14 & 15
9
1
