SWITCH ELEMENT TYPE
00
-
No Switches (empty housing)
M1
-
SPDT Mechanical
MA
-
SPDT Mechanical with Cams for 3-Position control (see note 1)
MD
-
DPDT Mechanical with Cams for DA 3-Position w/ Indication (see note 1)
MS
-
DPDT Mechanical with Cams for SR 3-Position w/ Indication (see note 1)
MC
-
SPDT Mechanical
– Construction for 250’ F
MG
-
SPDT Mechanical
– Gold Contacts
M3
-
DPDT Mechanical
– Cherry
MB
-
DPDT Mechanical
– Licon
P4
-
SPST Proximity
P5
-
SPDT Proximity
PE
-
Sabre SPDT Proximity
PP
-
Phazer II SPDT Proximity
PL
-
Phazer II SPDT Proximity with LED
PT
-
Phazer II BRS SPST Proximity
PX
-
Phazer II BRS SPST Proximity with LED
N8
-
P&F NJ2-V3-N / NJ2-V3-N-V5 (NAMUR)
N9
-
P&F NBB3-V3-Z4
NQ
-
P&F NJ4-12GK-N (NAMUR)
NR
-
P&F NJ4-12GM40-E1 (3-Wire NPN NO)
NS
-
P&F NJ4-12GM40-E2 (3-Wire NPN NO)
NT
-
P&F NJ4-12GK40-E2 (3-Wire NPN NO)
NP
-
P&F SJ3.5-N (NAMUR)
NU - GO SWITCH proximity
SN
-
3-Way Pneumatic Valves
FN
-
DeviceNet Controller Card, 4 in / 2 out, with (2) type 4 switches
FZ
-
AS-i 2.1 Controller Card, 4in / 2 out, with (2) type 4 switches
CERTIFICATIONS
-
(see note 2)
-14
-
General Purpose
-17
-
(CSA/UL) Class I, Div 1, CD; Class I Div 2, ABCD T3; Class II Div 1, EFG; Class II Div 2, FG;
Class III T5
-18
-
UL/CSA Cl I, Div 1 Gr CD / Cl II Div 1,2 Gr EFG/ ATEX II 2G Ex d IIB T5
-19
-
ATEX - II 2 G Ex d IIB T5; ; II 2 D Ex tD A21 IP 65
-25 - IECEx - Ex d IIB T5; Ex tD A21 IP 65
-26
-
InMetro
– BR Ex d IIB T5
-27
-
Factory Mutual/CUS Intrisically Safe Class I,II,III Div 1 Gr A,B,C,D,E,F,G T5 (See Note 7)
-M1
-
Metal Nameplate UL/CSA Cl I Div 1 Gr CD / Cl II Div 1,2 Gr EFG
-M2
-
Metal Nameplate UL/CSA Cl I Div 1 Gr CD Div 2 Gr ABCD T3 / Cl II Div 1,2 Gr EFG
