Flowserve 50165 Nordstrom Figure User Manual
Page 34
Nordstrom Figure 50165 and 50169 Dynamic Balance Iron Plug Valve FCD NVENIM2006-00 – 09/05
Detail Sketch: Stem End Detail –
Wrench Operated Valve
17
22
20
11
12
13
14
15
16
18
19
23
21
no.
item Description
11
Balance Ball
12
Spring
13
Check Valve
14
Sealant Fitting
15
O-Ring
16
O-Ring
17
Plug Stem
18
Gland
19
Cap Screw
20
Stop Collar
21
Ball Retaining Washer
22
Retainer
23
Weather Seal
