Connection to the ports
D
DVI -D
DVI-D jack (digital to digital)
Pin
Signal
Signal
Pin
Signal
Signal
1
T.M.D.S. Data 2 -
13
-
2
T.M.D.S. Data 2 +
14
+5V Power
3
T.M.D.S. Data 2/4 Shield
15
Ground (+5V, Analog H/V.sync)
4
-
16
Hot-Plug Sense
5
-
17
T.M.D.S. Data 0 -
6
SCL (DDC Clock)
18
T.M.D.S. Data 0 +
7
SDA (DDC Data)
19
T.M.D.S. Data 0/5 Shield
8
Analog V. sync
20
-
9
T.M.D.S. Data 1 -
21
-
10
T.M.D.S. Data 1 +
22
T.M.D.S. Clock Shield
11
T.M.D.S. Data 1/3 Shield
23
T.M.D.S. Clock +
12
-
24
T.M.D.S. Clock -
COMPONENT VIDEO
E
Y,
Y,
F
C
B
/P
B
,
G
G
C
R
/P
R
RCA jack x3
• System: 525i(480i), 525p(480p), 625i(576i), 750p(720p), 1125i(1080i)
Port
Signal
Signal
Y
Component video Y, 1.0±0.1Vp-p, 75Ω terminator with composite
C
B
/P
B
Component video C
B
/P
B
, 0.7±0.1Vp-p, 75Ω terminator
C
R
/P
R
Component video C
R
/P
R
, 0.7±0.1Vp-p, 75Ω terminator
H
H
S-VIDEO
Mini DIN 4pin jack
Pin
Signal
Signal
Signal
Signal
1
Color signal 0.286Vp-p (NTSC, burst), 75Ω terminator
Color signal 0.300Vp-p (PAL/SECAM, burst) 75Ω terminator
2
Brightness signal, 1.0Vp-p, 75Ω terminator
3
Ground
4
Ground
I
VIDEO
RCA jack
• System: NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43, PAL60
• 1.0±0.1Vp-p, 75Ω terminator
16 15 14 13 12 11 10 9
24 23 22 21 20 19 18 17
8 7 6 5 4 3 2 1
