Connection to the ports, Rgb in 1, Rgb in 2 – Dukane 8911 User Manual
Page 61: Rgb out, At rgb signal at component video signal, No connection), Ground, Y ground, Except for rgb out
Y
VIDEO
RGB IN1
RGB IN2
DVI-D
RGB OUT
CONTROL
AUDIO-IN
REMOTE
CONTROL
USB
DC OUT
S-VIDEO
LAN
COMPONENT VIDEO
C
B
/P
B
C
R
/P
R
R-AUDIO IN-L
AUDIO-OUT
Connection to the ports
Connection to the ports
A
A
RGB IN 1,
B
RGB IN 2,
C
RGB OUT
D-sub 15pin mini shrink jack
• Video signal: RGB separate, Analog, 0.7Vp-p,
75Ω terminated (positive)
• H/V. sync. Signal: TTL level (positive/negative)
• Composite sync. Signal: TTL level
At RGB signal At component video signal
Pin
Signal
Signal
1 Video Red
2 Video Green
3 Video Blue
4 (No connection)
5 Ground
6 Ground Red
7 Ground Green
8 Ground Blue
9 (No connection)
10 Ground
11 (No connection)
12
A
A : SDA (DDC data),
: SDA (DDC data), B / C : (No connection)
: (No connection)
13 H. sync / Composite sync.
14 V. sync.
15
A
A : SCL (DDC clock),
: SCL (DDC clock), B // C : (No connection)
: (No connection)
Pin
Signal
Signal
1
C
R
/P
R
2
Y
3
C
B
/P
B
4
(No connection)
(No connection)
5
Ground
6
C
R
/P
R
Ground
7
Y Ground
8
C
B
/P
B
Ground
9
(No connection)
(No connection)
10
Ground
11
15
(No connection)
* except for RGB OUT.
11 12
12 13
13 14
14 15
15
1
2
3
4
5
6
7
8
9 10
10
I
K
N
ONTROL
P
A
B
D
O
Q
H
E
F
J
R
M
L
C
G
59
