Desa CHDV36NR-C - Manual (Page 35)

111252-01E
For more information, visit www.desatech.com For more information, visit www.desatech.com
35
35
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 ** Burner Assembly Base 1
2 114443-01 Pan Burner Assembly 1
3 11165 Screw #10 x 5/8 MD TR BLK 12
4 108763-01 Tube Burner 1
5 104506-25 Pan Burner Orifice (Natural Gas #47) 1
104506-20 Pan Burner Orifice (Propane/LP Gas #56) 1
6 108084-02 Pilot Assembly (Natural Gas) 1
108084-03 Pilot Assembly (Propane/LP Gas) 1
7 11102 Screw #8-32 x 3/8 PPH Zinc 2
8 108755-01 Pilot Bracket 1
9 104506-26 Tube Burner Orifice (Natural Gas #50) 1
14544 Tube Burner Orifice (Propane/LPGas #59 ) 1
10 14528 Brass Elbow Fitting 1
11 14554 Tubing Assembly 1
12 14500 Brass Fitting 1
13 14389 Millivolt Valve (Natural Gas) 1
14390 Millivolt Valve (Propane/LP Gas) 1
14 14253 Flexible Gas Line 1
15 11107 Screw #10-32 x 1/4 PPH Zinc 4
16 26808 Valve Bracket 1
17 26827 Switch Bracket 1
18 14261 Piezo Ignitor 1
19 110986-01 Air Baffle (Natural Gas) 2
110986-02 Air Baffle (Propane/LP Gas) 2
20 108761-01 Grate Assembly 1
21 108754-01 Grate Base 1
**Not a field replaceable part.
PARTS LIST
BURNER ASSEMBLY FOR MODELS
(V)V36N-B, (V)V36P-B, VV36NC1, VV36PC1,
VV36NSC1, VV36PSC1, VV36PHC1, VV36NHC1 AND
CHDV36NR-C
This list contains replaceable parts used in your fireplace. When ordering parts,
follow the instructions listed under Replacement Parts on page 36 of this manual.
PARTS LIST
Models (V)V36N-B, (V)V36P-B, VV36NC1, VV36PC1,
VV36NSC1, VV36PSC1, VV36PHC1, VV36PHC1 and
CHDV36NR-C
