15
© 2003 Directed Electronics, Inc
FIGURE 5—PARALLEL SYNC GAINED 750d/1200/5
INPUT I/O
R
L
SLAVE MASTER
REMOTE
SLAVE IN
SYNC OUT
BRIDGE OUT
SUB LEVEL
MIN MAX
1+2 3+4 SUB 1-4 OUT SUB OUT
SYNC OUT
BRIDGE OUT
R
L
SLAVE MASTER
REMOTE
POWER
PROTECTION
1 Do Not Use
4 Do Not Use
2
Do Not Use
Master (1200/5)
Slave (750d)
3
MASTER
1200/5
SUBWOOFER SUB
-
+ - +
SLAVE
750D
+
-
-
+
-
+
5
Speaker Wiring (top view)
NNOOTTEE:: The dual + and -- sub-out terminals of the 750d are paralleled internally and the
combined load impedance should be taken into consideration when connecting multiple
subwoofers.
