signal processing
About the FX7's Effects
The FX7 has a large library of effects that covers virtually every possible need.
Because they are so numerous, we have designed the following charts to give
you as much relevant information as possible while omitting tedious or obvious
details about each module's setting. For example, Distortions, Tremolos,
Detuners, and Pitch Shifters are not shown because their Module names are rel-
atively self explanatory. The Fast Swell and Slow Swell Gates have attack times
of 500 ms and 1000 ms respectively.
The FX7 effects include:
EQUALIZERS
EQ# 1 2 3 4 5 6
Name Frq1/Gain1 F2/G2 F1/G1 F2/G2 F1/G1 F2/G2 F1/G1 F2/G2 F1/G1 F2/G2 F1/G1 F2/G2
Low Boost 100/8 6.3k/0 175/8 6.3k/0 275/8 6.3k/0 - - - - - -
Mid Boost 800/8 8k/0 1.25k/2 8k/0 2.2k/8 8k/0 - - - - - -
High Boost 1.6k/-3 3.4k/8 1.9k/-3 4.7k/10 2.2k/-5 8.5k/15 - - - - - -
Mid Cut 250/6 2.5k/4 500/6 4k/6 800/6 6.3k/9 150/9 2.5k/4 250/6 4k/8 400/6 5k/9
CHORUSES
Chorus # 1 2 3 4
Name Speed/Level Speed/Level Speed/Level Speed/Level
Slow 0.1/25 0.15/25 0.1/50 0.15/50
Medium .25/25 .35/25 .25/50 .30/50
Fast 2.0/25 3.5/25 2.0/50 3.5/50
FLANGERS
Flanger # 1 2 3 4
Name Speed/Fback Speed/Fback Speed/Fback Speed/Fback
Slow .1/40 .15/40 .15/50 .2/50
Medium .3/50 .35/50 .40/60 .40/60
Fast .7/60 .8/60 1.0/75 1.0/80
PHASERS
Phaser # 1 2 3 4
Name Speed/Fback Speed/Fback Speed/Fback Speed/Fback
Slow .1/60 .1/70 .15/80 .15/80
Medium .25/60 .25/70 .45/70 .45/80
Fast .9/40 1.0/50 1.5/50 2.0/60
12 FX7 owner's manual
