1144

© 2004 Directed Electronics, Inc

FIGURE 5—PARALLEL SYNC GAINED D1200/D2400

MASTER

SLAVE

Subwoofer Wiring (top view)

NNOOTTEE::

The dual + and -- sub-out terminals of
the D1200/D2400 are paralleled inter-
nally and the combined load impedance
should be taken into consideration when
connecting multiple subwoofers.

INPUT

R

L

INPUT

R

L

LINE OUT

SLAVE

MASTER

SLAVE

MASTER

MASTER AMPLIFIER

SLAVE AMPLIFIER

LINE OUT

0° 180°

PHASE

0° 180°

PHASE
