PARTS LIST
MODELS CF26PTA AND CF26NTA
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 27 of this manual.
KEY
PART
NO.
NUMBER
DESCRIPTION
QTY.
1
102633-02
Outer Casing Top
1
2
102624-02
Outer Casing
1
3
099230-02
Shoulder Screw
12
4
105631-01CK Assy. Hood Weldment
1
5
105258-01CK Vertical Front, Left and Right Sides
2
6
105259-01
Firebox Top
1
7
**
Firebox Wrapper
1
8
**
Bayfront Base
1
9
105421-01
Heat Deflector
1
10
105409-01
Fan Control Shield
1
11-1 105401-01
Screen Rod
1
11-2 105440-01
Screen Assembly
1
12
101386-02
Hinge
2
13
**
Rivets
8
14
105262-01CK Louvered Door
1
15
**
Firebox Floor
1
16
098304-01
Screw, #10 x 3/8”
21
17
105256-01CK Bayfront Bottom Panel
1
18
M11084-26
Hex Head Screws #10 x .38
26
19
105513-01CJ Cover, Screen Rod
1
20-1 105525-01
Fiber Brick, Left
1
20-2 105524-01
Fiber Brick, Rear
1
20-3 105526-01
Fiber Brick, Right
1
21
105987-01
Brick Liner Retainer
2
PARTS AVAILABLE — NOT SHOWN
103877-01
Lighting Instructions Plate
1
100563-01
Warning Plate
1
103470-01
Hardware Package
1
**Not a field replacement part.
