Datalogic Scanning DX8200A-3002 User Manual
Page 6
DX8200A-3002 QUICK GUIDE
6
Example of Redundant System Layout
AUX
CAB-SC6103
Extended I/O
ETHERNET
SC6000
CAB-SC6003
CAB-SC6003
Power/Net
VAC INPUT
PWO
LONWORKS
ENCODER
PS
PS Aux
CAB-850x
CAB-850x
BTK8500
CAB-850X
CAB-850x
CAB-850x
Extended I/O
ETHERNET
SC6000
CAB-SC6003
CAB-SC6003
Power/Net
VAC INPUT
PWO
CAB-PWO 03
Redundancy
CAB-850X
CAB-850x
CAB-850x
BTK8500
DX8200A DX8200A
DS8100A
DS8100A
ENCODER
PS
PS Aux
LONWORKS
Working
Controller
Protecting
Controller
to Host
to Host
DX8200A DX8200A
DS8100A
DS8100A
