Diamond Multimedia Radeon 9600 PRO User Manual
Page 22
18 Using Digital Flat Panel (DVI)
3
Turn on your DVI flat panel and your Mac.
Note: The DVI connector is hot swappable. You no longer need to
shut down your computer before attaching a digital flat panel.
A dual-link DVI transmits up to twice the amount of pixel information of
single link DVI connection. Use the dual-link DVI connector for extremely
high resolution displays such as Apple® 30-inch Cinema HD Displays.
Y
DVI-I Connector
Z
Single link DVI-I Monitor port
[
DVI-I Connector
