Using Digital Flat Panel (DVI) 17
Using Digital Flat Panel (DVI)
Use Radeon® 9600 PRO PC & Mac Edition’s DVI support feature to
output your computer’s display to your DVI digital flat panel, providing
you with:
• Crisper, clearer images.
• A true flat screen.
• Virtually no eye strain from prolonged viewing.
Using Radeon® 9600 PRO PC & Mac Edition DVI Connector
Use Radeon® 9600 PRO PC & Mac Edition to connect to a digital flat
panel display.
To output your computer’s display to a DVI digital flat panel
1
Looking at the back of your Mac, locate your ATI Graphics
Accelerator.
2
Attach one end of your DVI cable to the DVI connector on your
Radeon® 9600 PRO PC & Mac Edition and the other end to the DVI
connector on your DVI flat panel.
X
Dual Link DVI Monitor Port
