OWNER’S MANUAL
SPECIFICATIONS
BDV34N(A) BDV34P(A)
15,000/21,000 Btu/hr 16,000/20,000 Btu/hr
Gas Type Natural Propane
Ignition Piezo Piezo
Manifold Pressure 3.5" w.c. 10.0" w.c.
Minimum Inlet Supply Pressure 4.5" w.c. 11.0" w.c.
Dimension, Inches/mm (HxWxD)
Fireplace 33" x 34" x 18 1 /
2
" 33" x 34" x 18 1 /
2
"
838 x 940 x 470mm 838 x 940 x 470mm
Carton 37" x 40" x 21" 37" x 40" x 21"
940 x 1016 x 533mm 940 x 1016 x 533mm
Weight, lbs/kg
Fireplace 132 lbs/60 kg 132 lbs/60 kg
Shipping 135 lbs/61 kg 135 lbs/61 kg
