Indicator Display Screens
8 NT 460 User’s Manual D3840-US Rev A
INDICATOR DISPLAY SCREENS
Five display screens can be shown on the Indicator:
Field Screen
150 field names are available and can be modified using the keypad.
See page 9.
ID Screen
150 ID names are available and can be modified using the keypad.
See page 10.
GPS Active Screen
This screen is shown before pressing to start spreading. Upper
display shows gross weight while lower display includes speed,
compass direction, application rate, spread width, total and field name.
See page 11.
GPS Spreading Screen
Press before unloading to view GPS spreading screen. Upper
display shows the current rate tons/acre (tonnes/hectare) while lower
display includes speed, compass direction, target application rate, time
since start of unloading, gross weight, NET weight unloaded, acres
covered this load, and actual vs. target rate indicator. See page 12.
Last Load Summary Screen (temporary)
Screen display last load weights for 10 seconds after pressing
to complete a load. See page 13.
GPS Satellite Screen
Press to view GPS Satellite Screen. This screen shows
latitude, longitude, MPH, status and universal time clock. See page 14.
