Comtech EF Data MDX420 PLR5779 Demod Card Installation User Manual
Page 5
AN219 - Rev. A
MDX420 PLR5779 Demod Card Installation
Page 3
3.
Secure the PLR5779 Demod Card to the 3 standoffs using the supplied hardware.
Note: The supplied hardware includes (Part Number HW/4-40x1/4P.H.).
-
Three 4-40x1/4 pan head screws.
Figure 3. Secure PLR5779
4.
Reinstall the MDX420 lid.
Screw
Location
