Page 9
Page
Pos.
HT
-2145 D
HT
-2162 E
Part No.
Notes
Description
Specifications
4
1
2
374 008 345
GRIP
4
2
1
381 611 400
HANDLE(LEFT)
4
3
2
381 005 028
BOLT
4
4
1
374 136 103
HANDLE FITTING
4
5
1
381 611 600
BUSH
4
6
1
381 500 210
CORD BINDER
4
7
1
374 136 141
DRUM COMPLETE
4
8
3
381 406 016
BOLT
M6X16
4
9
1
381 500 010
GREASE NIPPLE
M6
4
10
2
381 405 000
U-NUT
M5
4
11
1
382 610 000
UPPER CASE
4
12
3
381 005 000
NUT
M5
4
13
2
381 406 001
BALL BEARING
UU 6001
4
14
1
381 202 800
SNAP RING
4
15
1
381 610 400
PINION GEAR
4
16
2
381 300 608
BALL BEARING
ZZ 608
4
17
1
381 610 300
CRANK GEAR ASSY
4
18
2
383 105 016
SCREW
M5-16
4
19
2
381 611 300
ROD
4
20
1
381 302 600
SNAP RING
4
21
1
381 610 200
CASE PACKING
4
22
1
381 811 200
STANDARD EQUIPMENT BLADE COVER
4
23
6
381 405 012
BOLT
M5X12
4
24
1
381 610 100
LOWER CASE
4
25
1
381 611 200
FELT
4
26
1
382 106 000
WAVE WASHER
4
27
1
381 000 400
SCREW
4
28
4
381 000 200
SCREW
L=19
4
29
5
374 008 250
BLADE SLIDING WASHER
4
30
1
381 850 580
STANDARD EQUIPMENT LOWER BLADE
4
31
1
381 850 560
STANDARD EQUIPMENT UPPER BLADE
4
32
1
381 610 500
HOLDING PLATE
4
33
1
374 605 998
CLAMP
4
34
5
381 406 000
U-NUT
M6
4
35
1
381 706 010
WASHER
M6
4
36
1
374 136 190
HANDLE (RIGHT)
4
37
1
381 224 600
LABEL
4
39
1
381 506 018
BOLT
M6X18
4
142
1
381 307 001
TUBE
4
143
1
367 373 000
SWITCH ASS'Y
4
144
1
367 115 000
SWITCH STAY
4
145
1
381 145 004
LABEL
4
146
1
367 050 250
SCREW
M5X25 (W/SW)
4
147
1
367 004 990
CONTROL CABLE
4
148
1
367 500 400
CONTROL LEVER
HT-2162 E
