Pos.
HT
-2145 D
HT
-2162 E
Part No.
Notes
Description
Specifications
1
1
1
374 155 000
FRONT HANDLE
1
2
2
381 106 000
NUT
M6
1
4
1
382 700 300
REAR HANDLE
INC. 5-15
1
5
1
381 508 800
SWITCH ASSY
1
6
1
381 710 800
STOPPER
1
7
1
381 710 500
REAR HANDLE(R)
1
8
1
381 302 300
SPRING
1
9
1
381 710 700
LOCK LEVER
1
10
1
381 302 400
SPRING
1
11
1
381 710 600
THROTTLE LEVER
1
12
1
381 710 400
REAR HANDLE (L)
1
13
1
381 217 500
LABEL
1
14
2
383 040 100
TAPPING SCREW
4X10
1
15
4
381 040 150
TAPPING SCREW
4X15
1
16
1
381 106 000
NUT
M6
1
17
1
381 506 055
BOLT
M6X55
1
18
1
381 224 600
LABEL
1
19
1
381 506 040
BOLT
M6X40
1
20
1
374 136 141
DRUM COMPLETE
1
21
1
381 710 000
CRANK CASE
1
22
2
381 406 016
BOLT
M6X16
1
23
2
381 405 000
U-NUT
M5
1
24
1
381 500 010
GREASE NIPPLE
M6
1
25
2
381 406 035
BOLT
M6X35
1
26
2
381 406 001
BALL BEARING
UU 6001
1
27
1
381 202 800
SNAP RING
1
28
1
381 610 400
PINION GEAR
1
29
2
381 300 608
BALL BEARING
ZZ 608
1
30
1
381 610 300
CRANK GEAR ASSY
1
31
1
381 302 600
SNAP RING
1
32
2
381 611 300
ROD
1
33
1
381 710 200
GASKET CASE
1
34
1
381 710 100
CRANK CASE COVER
1
35
7
381 405 012
BOLT
M5X12
1
36
2
381 105 016
SCREW
M5-16
1
38
4
381 406 000
U-NUT
M6
1
39
1
381 710 300
GUIDE PLATE
1
40
1
381 850 600
STANDARD EQUIPMENT UPPER & LOWER BLADE
1
41
1
381 906 000
WAVE WASHER
1
42
1
381 611 200
FELT
1
43
4
374 008 250
BLADE SLIDING WASHER
1
44
4
381 000 200
SCREW
L=19
1
45
1
381 850 600
STANDARD EQUIPMENT UPPER & LOWER BLADE
1
46
1
381 800 208
STANDARD EQUIPMENT BLADE COVER
HT-2145 D
