Major Assembly
The Comtech EF Data Digicast Media Router CMR-5970 (MR-S2) and CMR-5990 (MR-S2-ASI) are each available in a
standalone configuration. The following table lists the components provided with a standard configuration. In the event
any listed item is missing, please contact Comtech EF Data Customer Support.
Digicast Media Router MR-S2 or MR-S2-ASI Standalone Configuration
Quantity Description
1 CMR-5970 [MR-S2] or CMR-5990 [MR-S2-ASI]
1 SPU30-102 Power Supply
1 IEC Power Cable
1 CA-TERMINAL Terminal Cable
1 CD (including Quick Start reference and Installation and Operation Manual)
1 Quick Start sheet
Installation
The MR-S2 is designed for ease of installation and configuration. Once the unit has been removed
from the packing container, please follow these instructions:
Step Procedure
1 Place the MR-S2 on a flat surface with free-air flow where the LEDs can be clearly
observed with unrestricted access to the rear panel of the unit.
2 It is suggested that the coaxial connection to the Low Noise Block (LNB) NOT be
connected to the unit until the unit has been fully configured. If the unit will not be
powering the LNB, it is recommend that an F-Type DC Block be installed on the input to
the MR-S2’s L-Band input
3 Connect the DC power connection to the connection labeled PWR on the back of the unit
and tighten the restraining nut to ensure secure operation.
4 Connect an RJ-45 Ethernet cable (patch cord) to the port labeled ETHERNET. This cable
should be connected to an Ethernet concentrator (hub) or switch.
5 Connect a terminal cable (supplied) to the port labeled TERM. This cable should be
connected to a PC’s serial port (DB-9) to initially configure the MR-S2.
6 Connect the AC power cord between a standard wall outlet and the power supply. The
Blue LED will illuminate.
7
IMPORTANT
It is recommend that the ASI cable NOT be connected until the unit has been
completely configured.
Upon startup, the following LEDs will illuminate on the MS-R2 front panel:
LED
Function
Label
Description
Blue PWR LED illuminates if power is properly applied
Red ALARM LED may illuminate since the unit is not yet configured
Green LOCK LED illuminates if the tuner is locked
Green E-RX
Green E-TX
LED flashes if there is Ethernet traffic/activity
8
Green E-LINK
LED illuminates if the Ethernet connection to the
Hub/Switch is operational
