Major Assembly
The CME-5200 Digicast Media Router ASI-R is available in a standalone configuration. The following table
lists the components provided with a standard configuration. In the event any listed item is missing, please
contact Comtech EF Data Customer Support:
CME-5200 Digicast Media Router ASI-R
Quantity
Description
1
CME-5200 Digicast Media Router ASI-R
1
SPU24-102 Power Supply
1
IEC AC Power Cord
1
CA-TERMINAL Terminal Cable
1
CD (includes Quick Start reference and Installation and Operation Manual)
1
Quick Start sheet
Installation
The ASI-R is designed for ease of installation and configuration. Once the unit has been removed from the
packing container, please follow these instructions:
Step
Procedure
1
Place the ASI-R on a flat surface with free-air flow where the LEDs can be clearly observed with
unrestricted access to the rear panel of the unit.
2
Connect the DC power connection to the connection labeled PWR on the back of the unit and tighten the
restraining nut to ensure secure operation.
3
Connect an RJ-45 Ethernet cable (patch cord) to the port labeled ETHERNET. This cable should be
connected to an Ethernet concentrator (hub) or switch.
4
Connect a terminal cable (supplied) to the port labeled TERM. This cable should be connected to a PC’s
serial port (DB-9) to initially configure the ASI-R.
5
Connect the AC power cord between a standard wall outlet and the power supply. The blue LED will
illuminate.
6
IMPORTANT
It is recommend that the ASI cable NOT be connected until the unit has been
completely configured.
Upon startup, the following LEDs will illuminate on the ASI-R front panel:
LED
Function Label
Description
Blue
POWER
LED illuminates if power is properly applied
Red
ALARM
LED may illuminate since the unit is not yet configured
Green
M-ACT
LED illuminates if MPE data is present
Green
E-ACT
LED flashes if there is Ethernet traffic/activity
7
Green
E-LINK
LED illuminates if the Ethernet connection to the
Hub/Switch is operational
