PLANNING

GUIDE

Web: http://www.Dacor.com

Corporate Phone: 800-793-0093

Specifications are subject to change without notice.

See installation instructions for additional details.

5.2

30” Wide,

Epicure™ Range

EGR30

2/2

Revised

07/30/08

Model Number

“a” Cabinet width

“B” Hood width

EGR30

30 1/16” (764mm)

30” (762mm)

cAbINEt DImENsIONs

**

** Cabinet depth is at discretion of customer

but cabinet face MUST NOT protrude further

than rear of front panel, see product dimesions

* Vertical to combustible surface

B

A

Non-Combustible

surface along

back wall

Suggested

location of

utilities

30” (762mm)

min.*

29 1/4" (743mm)

13/32"

(10mm)

30 1/16" (764mm)

3/4" (19mm)

Max. backsplash

1/4" (6mm)

Min. flat ledge

13/16" (21mm)

23 3/16"

(589mm)

Vertical

non-combustible

surface

Rear wall

25"

(635mm)

Countertop

Countertop

tOP vIEW

cUtOUt DImENsIONs

(Slide-In, Self-Rimming Installation with Side Panels and Backguard Removed)

All tolerances +1/16” -0 (+1.6 mm, 0) unless otherwise noted.
