Daewoo DVQ-13H1FC - Manual (Page 43)

42
RCU07 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RCU08 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RCU09 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RCU10 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RCU11 HRFT273JCA R CHIP 1/10 27K OHM J 2012
RCU12 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RCU13 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RCU14 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCU15 HRFT512JCA R CHIP 1/10 5.1K OHM J 2012
RCU16 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RCU19 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RCU20 HRFT229JCA R CHIP 1/10 2.2 OHM J 2012
RCU21 HRFT229JCA R CHIP 1/10 2.2 OHM J 2012
RCU22 HRFT334JCA R CHIP 1/10 330K OHM J 2012
RCU23 HRFT123JCA R CHIP 1/10 12K OHM J 2012
RCU24 HRFT221JCA R CHIP 1/10 220 OHM J 2012
RCU25 HRFT822JCA R CHIP 1/10 8.2K OHM J 2012
RCU26 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RCU27 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RCU28 HRFT512JCA R CHIP 1/10 5.1K OHM J 2012
RCU29 HRFT683JCA R CHIP 1/10 68K OHM J 2012
RCU30 HRFT512JCA R CHIP 1/10 5.1K OHM J 2012
RCV01 HRFT750JCA R CHIP 1/10 75 OHM J 2012
RCV02 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RCY01 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RCY02 HRFT331JCA R CHIP 1/10 330 OHM J 2012
RCY03 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RCY04 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RCY05 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RCY06 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RCY07 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RCY08 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCY11 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCY12 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCY13 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RCY14 HRFT511JCA R CHIP 1/10 510 OHM J 2012
RCY15 HRFT201JCA R CHIP 1/10 200 OHM J 2012
RCY16 HRFT201JCA R CHIP 1/10 200 OHM J 2012
RCY17 HRFT182JCA R CHIP 1/10 1.8K OHM J 2012
RCY18 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCY19 HRFT182JCA R CHIP 1/10 1.8K OHM J 2012
RCY20 HRFT822JCA R CHIP 1/10 8.2K OHM J 2012
RCY21 HRFT182JCA R CHIP 1/10 1.8K OHM J 2012
RCY24 HRFT102JCA R CHIP 1/10 1K OHM J 2012
LOC PART CODE PART NAME DESCRITION
RCY25 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RCY26 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RCZ01 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RCZ02 HRFT183JCA R CHIP 1/10 18K OHM J 2012
RCZ03 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RCZ04 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RCZ06 HRFT471JCA R CHIP 1/10 470 OHM J 2012
RCZ09 HRFT220JCA R CHIP 1/10 22 OHM J 2012
RCZ10 HRFT751JCA R CHIP 1/10 750 OHM J 2012
RLY01 5SC0101338 SW RELAY DQ5D1-O(M)/GJ-SS-105LM
RS13 RD-4Z121J- R CARBON FILM 1/4 120 OHM J
RS26 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
RS27 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RS41 RD-4Z472J- R CARBON FILM 1/4 4.7K OHM J
RS42 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RS43 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RS44 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RS45 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RS58 RD-4Z471J- R CARBON FILM 1/4 470 OHM J
RS59 RD-4Z471J- R CARBON FILM 1/4 470 OHM J
RS83 RN02B339JS R METAL FILM 2W 3.3 OHM J SMALL
RS88 RD-4Z103J- R CARBON FILM 1/4 10K OHM J
RS90 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RS91 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
RT01 RD-4Z240J- R CARBON FILM 1/4 24 OHM J
RT10 RD-4Z681J- R CARBON FILM 1/4 680 OHM J
RT16 RD-4Z681J- R CARBON FILM 1/4 680 OHM J
RU17 RD-4Z561J- R CARBON FILM 1/4 560 OHM J
RU18 RD-4Z470J- R CARBON FILM 1/4 47 OHM J
SCT01 4859303430 SOCKET CRT PCS633A
SS01 TST5811--- TR PHOTO ST-5811
SS01A 97P2343500 HOLDER TR ABS FR
SS02 TST5811--- TR PHOTO ST-5811
SS02A 97P2343500 HOLDER TR ABS FR
SS03 1SG239S--- IC SENSOR SG-239S
SS04 1SG239S--- IC SENSOR SG-239S
SWS01 5SN0101Z20 SW DETECT JDS1105-6X
SWT01 5S50101090 SW TACT SKHV17910A
SWT02 5S50202002 SW TACT KPT-2105A 2C-2P
SWT03 5S50202002 SW TACT KPT-2105A 2C-2P
SWT04 5S50101090 SW TACT SKHV17910A
SWT05 5S50101090 SW TACT SKHV17910A
SWT06 5S50101090 SW TACT SKHV17910A
SWT07 5S50101090 SW TACT SKHV17910A
LOC PART CODE PART NAME DESCRITION
ELECTRICAL PARTS LIST
