Duracell N User Manual
Zn/mno, Typical discharge characteristics at 21 c (70 f)
N
Alkaline-Manganese Dioxide Battery
Size: MN 9100 (LR1)
Nominal Voltage:
1.5 V
Nominal Internal
Impedance:
420 m-ohm @ 1kHz
Average Weight:
9.0 gm (0.3 oz.)
Volume:
3.4 cm
3
(0.21 in.
3
)
Terminals:
Flat
Operating Temperature
Range:
-20
o
C to 54
o
C
(-4
o
F to 130
o
F)
NEDA/ANSI:
IEC:
910A
LR1
0.5 mm
MIN.
(
+
)
12.0
10.9
4.7 mm
Max.
(
–
)
30.2
29.1
Dimensions shown are IEC/ANSI standards
mm
mm
5.0 mm
MIN.
Typical Discharge Characteristics at 21 C (70 F)
0.8
0.9
1
1.1
1.2
1.3
1.4
1.5
1.6
0
0.5
1
1.5
2
2.5
3
Hours of Service
Voltage
5.1 OHM
o
o
This data is subject to change. Performance information is typical. Contact Duracell for the latest information
6/08
Delivered capacity is dependent on the applied load, operating temperature and cut-off voltage. Please refer to the charts
and discharge data shown for examples of the energy / service life that the battery will provide for various load conditions.
*
Zn/MnO
2
