CEF14

Charge Sizes: AA , AAA

Value Charger for NiMH Batteries

NiMH

Technical

Battery Charger:

Class 2, Integrated Power Supply

Plug:

Direct Plug-In Matches Local Requirements

Battery Type/Fit:

NiMH: 2 or 4 AA/HR6, NiMH: 2 or 4 AAA/HR03

Typical Weight:

207 g

Input:

100-240V AC, 50-60 Hz, 7w

Output:

AA/HR6: 3.0V DC 360 mA

AAA/HR03: 3.0V DC 180 mA

Operating Temp:

0°C - 35°C (32°F - 95°F)

Dimensions:

123 mm (H) x 72 mm (W) x 42 mm (D)

SAFETY

Microprocessor Controlled

Charge termination based on –dV/dt, temperature, and/or built-in timer

Over-temperature shutoff- prevents overheat of cell

Primary cell protection- will not charge non-rechargeable batteries

Low voltage battery protection- prevents overheat and damage to cell

Power protection circuit- resets whenever a battery is removed

Berkshire Corporate Park
Bethel, CT 06801 U.S.A.
Tel: Toll free 1.800.544.5454
Web: www.duracell.com

BATTERIES

Information and contents in this data sheet are for reference purposes only. They do not constitute any warranty and representation is
subject to change without notice. For most current information and further details, please contact Duracell.

*Charge rate and time is dependent on cell capacity, discharge state, and operating temperature.

BENEFITS

Great Value, New Sleek & Compact Design, Convenient Wall Plug-In

FEATURES

Independent Channel Charging

Fully Charges cells in 6 hours*

Charges both AA and AAA NiMH cells

Ensures a full charge regardless of charge or battery capacity

LED Indicates Charge

Red = Charging

Green = Complete

Flashing Red = Error/Abnormal battery or abnormal temperature

Maintenance Charge Keeps Cells Fresh

International Charge Capability- device can be used worldwide with suitable converter plug

Document #: CH-A
