5 VS4x1 & VS8x1 Video Switch
Jumper/switch settings:
VS4x1R:
Switch S6
Function Position
1 Follow Mode Up-Off, Down-On
2 Sync Detection Up-On, Down-Off
3 not used
4 not used
VS8x1R:
Jumper
Function Position
W9 Follow Mode In-Enabled, Out-Disabled
W10 Sync Detection In-Enabled, Out-Disabled
RS232 Commands:
Command
Function
Vx Switches video to “x” channel
Ax Switches audio to “x” channel
Bx Switches both video and audio (AS4x1R)
to “x” channel
CC Responds with Current Channel,
Vx (VS8x1R only)
Responses from switchers:
Responses
Function
NV No Video present (if video detect is enabled)
KE Keyboard Error (invalid code sent)
KT Keyboard Time-out error (5 second time-span
to get the data sent to the VS switcher)
Vx Successful video switch to the “x” channel
(only if video is present on the input)
Bx Used in conjunction with the AS4x1R,
successful audio/video switch to the “x”
channel (only if video is present on the input)
