www.desatech.com 111826-01G 29
kEY
NO. PART NO.
DESCRIPTION QTY.
1 1119-01 Grate Assembly • • 1
2 11194-06 Valve-Bracket Assembly • • 1
11194-02 Valve-Bracket Assembly • • 1
11182-01 Log Assembly • • 1
111802-01 Log Assembly • • 1
4 11180-02 Right Burner Bracket • • • • 1
5 11180-01 Left Burner Bracket • • • • 1
6 111800-01 Screw • • 19
111800-01 Screw • • 15
11181-01 Flextube /8" • • • • 1
8 1496 Adapter • • • • 1
9 111804-01 Burner • • 1
111804-02 Burner • • 1
10 111819-01 Elbow Orifice • • 1
111819-0 Elbow Orifice • • 1
11 11180-01 Valve NG • • 1
11180-02 Valve LP • • 1
12 11691-01 Valve Bracket • • • • 1
1 11145-01 Electronic Ignitor • • • • 1
14 1084-01 Control Knob Extension • • • • 1
15 1084-02 Control Knob Extension • • • • 1
16 099998-01 Fan Switch • • • • 1
1 112806-01 Remote Control Assembly • • 1
18 112806-02 Remote Bracket • • 1
19 11181-02 Flextube /16" • • • • 1
20 11196-02 Pilot Shield • • • • 1
21 1126-01 Pilot • • 1
108-01 Pilot • • 1
22 111828-01 Compression Nut/Sleeve • • • • 1
2 11180-0 NG Air Shutter • • 1
24 111824-01 Compression Nut/Sleeve • • • • 1
25 111816-01 Screw • • • • 4
PARTS AVAILABLE NOT SHOWN
10056-01 Warning Plate • • • • 1
108-01 Lighting Instruction Plate • • • • 1
100565-01 Warning Plate Fastener • • • • 1
10069-01 Caution Decal • • • • 1
GA6060 Lava Rock • • • • 1
111288-02 Gas Flex Line 18" • • • • 1
1126-01 Log Scrap Kit #1 • • • • 1
11264-01 Log Scrap Kit #2 • • • • 1
PARTS LIST
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 24 of this manual.
v
F-24N-BTB
VF-24P-BTBVF-24N-PDGVF-24P-PDG
