www.desatech.com 111826-01G 2
PARTS LIST
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 24 of this manual.
kEY
NO.
PART NO. DESCRIPTION QTY.
1 111808-01 Grate Assembly • • • • 1
2 11194-0 Valve-Bracket Assembly • • 1
11194-04 Valve-Bracket Assembly • • 1
11184-01 Log Assembly • • 1
11185-01 Log Assembly • • 1
4 11180-05 Right Burner Bracket • • • • 1
5 11180-04 Left Burner Bracket • • • • 1
6 111800-01 Screw • • 19
111800-01 Screw • • 15
11181-01 Flextube /8" • • • • 1
8 1496 Adapter • • • • 1
9 111804-04 Burner • • 1
111804-0 Burner • • 1
10 111819-04 Elbow Orifice • • 1
111819-05 Elbow Orifice • • 1
11 11180-01 Valve NG • • 1
11180-02 Valve LP • • 1
12 11691-01 Valve Bracket • • • • 1
1 11145-01 Electronic Ignitor • • • • 1
14 1084-01 Control Knob Extension • • • • 1
15 1084-02 Control Knob Extension • • • • 1
16 099998-01 Fan Switch • • • • 1
1 112806-01 Remote Control Assembly • • 1
18 112806-02 Remote Bracket • • 1
19 11181-02 Flextube /16" • • • • 1
20 11196-02 Pilot Shield • • • • 1
21 1126-01 Pilot • • 1
108-01 Pilot • • 1
22 111828-01 Compression Nut/Sleeve • • • • 1
2 11180-0 NG Air Shutter • • 1
24 111824-01 Compression Nut/Sleeve • • • • 1
25 111816-01 Screw • • • • 4
PARTS AVAILABLE NOT SHOWN
10056-01 Warning Plate • • • • 1
108-01 Lighting Instruction Plate • • • • 1
100565-01 Warning Plate Fastener • • • • 1
10069-01 Caution Decal • • • • 1
GA6060 Lava Rock • • • • 1
111288-02 Gas Flex Line 18" • • • • 1
1126-01 Log Scrap Kit #1 • • • • 1
11264-01 Log Scrap Kit #2 • • • • 1
VF-18N-BTBVF-18P-BTBVF-18N-PDGVF-18P-PDG
