RECOMMENDED ENCLOSURES
HP10
Sealed
Optimum
Large
Vented
All Around
Vb (ft
3
)
0.6
1.25
Vb (ft
3
)
1.25
F3 (Hz)
51
52
Fb/F3 (Hz)
42 / 33
Qtc
0.705
0.592
Port/s (in.)
(dia. x length)
4 x 16.25
Pe (W)
1000
600
Pe (W)
800
HP12
Sealed
Optimum
Large
Vented
All Around
Vb (ft
3
)
1.0
2.0
Vb (ft
3
)
1.75
F3 (Hz)
47
48
Fb/F3 (Hz)
35 / 29
Qtc
0.689
0.59
Port/s (in.)
(dia. x length)
4 x 16
Pe (W)
1200
800
Pe (W)
1000
HP15
Sealed
Optimum
Large
Vented
All Around
Vb (ft
3
)
1.65
2.0
Vb (ft
3
)
2.5
F3 (Hz)
44
44
Fb/F3 (Hz)
36 / 32
Qtc
0.747
0.703
Port/s (in.)
(dia. x length)
(2) 4 x 25
Pe (W)
1500
1500
Pe (W)
1500
The enclosures specified below are offered as suggestions only. Assistance from an authorized
Diamond Audio retailer is recommended for designing the correct system for your vehicle. All volumes
below are shown as gross internal volumes, driver and vent displacement has been accounted for. The
use of a 30 Hz. sub-sonic filter is recommended on most vented enclosures.
