31
Specifications
MODEL NAME DLP-20J1 DLP-20D7 DLP-20W2
PANEL 20” TFT LCD
SCREEN SIZE 510.54mm(diagonal) 509.00mm(diagonal)
DISPLAY COLOUR 16.7M 16.2M
CONTRAST RATIO 700:1 600 : 1
PIXEL PITCH 0.6375(H) x 0.6375(V) 0.32475(H) x 0.32475(V)
ASPECT RATIO 4:3 16 : 9
POWER REQUIREMENT AC 220 ~ 240V, 50Hz
POWER CONSUMPTION 50W 45W 53W
SOUND OUTPUT 2.0W + 2.0W
APPEARANCE(mm) 514(W) x 498(H) x 257.3(D) 608(W) x 456(H) x 215(D) 509(W) x 420.5(H) x 239(D)
WEIGHT 7.9Kg 8.35Kg 7.5Kg
RESOLUTION 640 x 480 1366 x 768
TERMINALS AV IN : SCART, COMPOSITE VIDEO, S-VIDEO, AUDIO L/R
HEADPHONE : 3.5mm STEREO MINI-JACK
ANT. IN : COAXIAL-TYPE
RECEPTION CHANNEL CCIR + CATV + HYPER Channel
VHF-L : NZ1 ~ S7 (42.25MHz ~ 147.25MHz)
VHF-H : S8 ~ S36 (154.25MHz ~ 423.25MHz)
UHF : S37 ~ E69 (431.25MHz ~ 855.25MHz)
The specification shown above may be changed without prior notice for quality
improvement (Weight and Dimensions shown are approximate).
