Clearances – DCS -DRH48N User Manual
Page 7
6
Clearances
10"
SIDE VIEW
23"
30
0
max.
4 bolts per
bracket
Surface
Combustible
(not supplied)
FLOOR
96"
1/2" Conduit
(not supplied)
Gas Shut
Off Valve
(not supplied)
Gas Pipe
(not supplied)
Utilize 2
bolts (min)
per bracket.
Drip Leg
min.
Min
30
0
I n s t a l l a t i o n
Minimum clearances to combustible material.
N o t e : Mounting channels can be hacksawed 13” for use in 30
0
i n s t a l l a t i o n s .
