Clearances – DCS -DRH48N User Manual
Page 6
5
Clearances
21"
7 3/4"
10 1/4"
Side View
FLOOR
On Each Side
(not supplied)
14"
96"
(MIN)
(MIN)
(MIN)
1/2" Conduit
Drip Leg
(not
supplied
)
Gas Shut
(not supplied)
Gas Pipe
(not supplied)
Utilize 2
bolts (min)
per bracket.
Utilize 2
bolts (min)
per bracket.
Surface
Combustible
Off Valve
Four Bolts Two
0
0
I n s t a l l a t i o n
Minimum clearances to combustible material.
