Cavity

Cartridge

Fuse

Mini Fuse

Description

6

—

10 Amp Red

Ignition Off
Draw (IOD) –
Power Mirror
Switch/Climate
Controls

7

—

30 Amp

Green

Ignition Off
Draw (IOD)
Sense 1

8

—

30 Amp

Green

Ignition Off
Draw (IOD)
Sense 2

9

40 Amp

Green

Battery Feed –
Power Seats – If
Equipped/PZEV
Air Pump –
If Equipped

Cavity

Cartridge

Fuse

Mini Fuse

Description

10

—

20 Amp

Yellow

Battery Feed –
Cabin Compart-
ment Node
(CCN)

11

—

15 Amp Lt

Blue

Selectable Power
Outlet

12

—

20 Amp

Yellow

—

13

—

20 Amp

Yellow

—

14

—

10 Amp Red

Ignition Off
Draw (IOD) –
Cabin Compart-
ment Node
(CCN)/Interior
Lighting

384
