Carefully unpack the machine and all loose items from
the shipping container(s). Remove the protective coating
from all unpainted surfaces. This coating may be removed
with a soft cloth moistened with kerosene. (Do not use
acetone, gasoline or lacquer thinner for this purpose.) After
cleaning, cover the unpainted surfaces with a good quality
household floor paste wax.
1. Remove the four bolts (A) Fig. 1 (three of which are
shown) that attach the saw (B) to the shipping skid.
2. Save the four bolts to permanently mount the saw to
a supporting surface.
Fig. 1
B
A
A
THIS MACHINE IS HEAVY AND CAN TILT EASILY. USE FOUR OR MORE PEOPLE TO SLIDE THE
MACHINE OFF OF THE SHIPPING SKID.
9
UNPACKING AND CLEANING
ASSEMBLY
FOR YOUR OWN SAFETY, DO NOT CONNECT THE MACHINE TO THE POWER SOURCE UNTIL
THE MACHINE IS COMPLETELY ASSEMBLED, AND YOU READ AND UNDERSTAND THE ENTIRE
INSTRUCTION MANUAL.
ON/OFF SWITCH
1. Remove the two screws (A) Fig. 3 on the cover of the on/off switch, and remove the front cover.
2. Align the two holes of the On/Off switch with the two holes (B) Fig. 4 on the front of the saw.
3. Thread the two screws (located loose in the switch box) into the two holes in the front of the saw and tighten securely.
4. Replace the front cover of the On/Off switch that was removed in STEP 1.
ASSEMBLY TOOLS REQUIRED
ASSEMBLY TIME ESTIMATE - 2 to 4 hours
* 5mm Hex Wrench (supplied)
* Phillips head screwdriver (not supplied)
Fig. 3 Fig. 4
A
B
A
