6 Stove Installation
(for qualified installers only)
© Travis Industries 100-01234 4141211
Installation Options
 Masonry Fireplace Insert
 Zero-Clearance (Metal) Fireplace Insert
Features
 2.2 Cubic Foot Firebox Volume
 Single Operating Control
 Accepts Logs Up to 18" Long
 Steel Plate Construction (5/16" & 1/4")
 Heavy Duty Refractory Firebrick
 Standard High-Tech Blower
 Optional High-Tech Blower
Heating Specifications
Approximate Maximum Heating Capacity (in square feet)* 1,200 to 2,000
Maximum Burn Time Up to 10 Hours
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside
temperature. It is also affected by the quality and moisture level of the fuel.
This model was not tested for efficiency however it is assigned a default efficiency of 63% by the EPA
under previous subpart AAA. Efficiency of this wood heater will be affected by the operational burn rate
and the moisture content of the wood used as fuel.
Dimensions
21-3/8"
(543mm)
13-1/8" (334mm)
21-5/8" (550mm)
380 Lbs. (170 Kg)
5-3/16"
(132mm)
19-3/4"
(502mm)
10" (254mm)
24-1/4"
(616mm)
18-3/4"
(477mm)
a
b
Figure 1
(a) Measure side and top clearances from the top plate. Measure front clearances from the stove face
(b) Fireplace Opening
Emissions
This heater meets the 2015 U.S. EPA’s crib wood emission limits for wood heaters sold after May 15,
2015. Tested to Method 28, 5H this heater has been shown to deliver heat at rates ranging from 9,300 to
42,200 BTU/hr and an emission value of 1.9g/h.
