Controls, LEDs, and Connectors
XMCSPAN Installation and Use (6806800H03C) 38
4.3.2 LED Information
The XMCSPAN has two front panel LEDs: PWR and RESET. The PWR LED is illuminated red if the
on-board supplies are not functioning properly. The PWR LED is off when the supplies are
good. The RESET LED is illuminated yellow if the board is in reset.The RESET LED is illuminated
green when not in reset.The XMCSPAN-001 has LEDs that are mounted on the surface of the
PWB and not visible from the front panel. The function of these LEDs is described in the tables
below.
26 GND PMC1IO_52 - PMC1IO_51 PMC2IO_39
27 PMC2IO_41 PMC1IO_54 - PMC1IO_53 PMC2IO_40
28 GND PMC1IO_56 - PMC1IO_55 PMC2IO_42
29 PMC2IO_44 PMC1IO_58 - PMC1IO_57 PMC2IO_43
30 GND PMC1IO_60 - PMC1IO_59 PMC2IO_45
31 PMC2IO_46 PMC1IO_62 GND PMC1IO_61 GND
32 GND PMC1IO_64 +5V PMC1IO_63 VPC
Table 4-2 Pin definition for VME connector P2
Pin Row Z Row A Row B Row C Ro
Table 4-3 PEX 8533 PCIE Switch
LED Description Color
D10 PEX_PORT_GOOD_0 Amber
D9 PEX_PORT_GOOD_1 (For
more details, refer
Table
"Tsi384 PCIE-PCIX PMC2"
on page 39
)).
Amber
D8 PEX_PORT_GOOD_2 Amber
D7 PEX_PORT_GOOD_8 Amber
