23- ENG

D27456

PARTS LIST

Key No

Part Number

Description

1

★ —————

Shroud, Left

2

★ —————

Shroud, Right

3

D25877

Cylinder Head

4

*

CAC-1212

Tube Seal

5

*

CAC-1199

Gasket Head

6

Z-D29777

Valve Plate Assembly

7

DAC-269

Outlet Tube

8

*

SSG-8169

O-ring

9

+ —————

Rod Assembly

10

CAC-1206-1

Hose Clamp

11

AC-0206

Isolator Tube

12

x SSF-3147

Screw, 3/8-16 x .375

13

+ —————

Cylinder Sleeve

14

—————

Endbell Assembly

15

x SUDL-9-1

Screw, 8-32x .375/.344

16

AC-0815

Timing Belt

18

x SSF-3156

Screw, 10-9x.50 Plastite (5 used)

20

*

D25731

Pump Isolator (5 used)

21

x SSF-995

Screw #10-24 x 7/8 (4 used)

Not Shown
A00766

Motor Cord

SSH-20

Air Chuck

H-7040-1

Air Hose

Kits Available

★ A06436

Left/Right Shroud Kit

* K-0387

Isolator

Kit

+ KK-4964

Connecting Rod Kit

x KK-4929

Fastener

Kit
