DA100 MKII
stello DA100 MKII DSD DAC page 17
Specification
DIGITAL INPUTS 1 x USB 2.0
1 x COAX
2 x OPT
1 x AES/EBU
PC USB Link High Speed USB Audio Interface with
FPGA Based Audio Processor
Mac OSX 10.6+
Linux with UAC2 Compliant kernel
Windows OS
SAMPLE RATE AES/EBU, COAX - up to 192kHz depending on source
SPDIF compliant digital audio output
OPT IN – up to 96kHz(will work up to 192kHz
depending on the source device SPDIF signal
quality)
USB - PCM 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384kHz
USB - DSD64, DSD128
UPSAMPLING Bidirectional Estimator
Up to 384kHz
ANALOG
OUTPUTS 1 x RCA
1 x XLR
OUTPUT
SIGNAL LEVEL Unbalanced 2.6Vrms
Balanced 2.6Vrms on each leg
